Body Dimensions：Length: 3.28m, Width: 1.68-1.70m, Height: 2.2m
Lifting Height：2-stage 3m (Mast width: 16#), Shandong Laigang B Series mast
Load Center Distance：500mm
Mast Width (Full)：Dual mast: 800mm, Triple mast: 800mm
Mast Material：20MnSiV steel
Vehicle Weight：Standard: 4.8-4.9T, Triple mast: 5.2-5.3T
Engine (China IV)：Quanchai 495 VP pump (natural aspiration), East China 490 (turbocharged VP pump), +¥700 for Quanchai 495 common rail version
Engine Power：Quanchai: 42kW, East China: 55kW
Transmission：OEM by renowned manufacturer (self-developed)
Full-time 4WD：High-low speed, Forward-reverse dual pushrod
Speed：CVT: 27-28 km/h
Performance：Low-speed high torque, Excellent off-road capability
Drive System：CVT, Full mechanical gear transmission (Non-traditional cross-axis)
Axles：Front: Mini planetary reduction axle
Rear: 80° steering (pivot turn capable, self-developed)
Tires：Front: Semi-pneumatic 20.5-16 (880×300mm, off-road tread)
Rear: Semi-pneumatic 7.50-16 (750×190mm, off-road tread), Chaoyang brand
Tire Pressure：6 MPa
Gradeability：Unloaded: 35°, Loaded: 25°
Ground Clearance：Mast: 250mm, Chassis: 320mm
Counterweight：Solid cast iron
Tilt AnglesFront/Rear tilt: 12°
Turning Radius：Front: 0.25m, Rear: 2.6m
Wheelbase：2150mm
Features：Full-time 4WD with open differential
Suitable for basements/rental use
Adaptable to mud, snow, slopes
Braking System：Front wheel braking
Ex-factory Price：(Excluding tax and transportation)
