Body Dimensions：Length: 3.28m / Width: 1.68-1.70m / Height: 2.2m
Lifting Height：2-stage 3m (Gate frame width: 16#); Gate frame origin: Shandong Laigang B Series
Load Center Distance：500mm
Gate Frame Width (Full)：Dual gate frame: 800mm / Three-stage gate frame: 800mm
Gate Frame Material20MnSiV (Manganese Silicon Vanadium Steel)
Vehicle Weight：Standard: 4.8-4.9T / Three-stage gate frame: 5.2-5.3T
Engine (China IV)：Quanchai 495 VP pump naturally aspirated / East China 490 turbocharged VP pump (Quanchai 495 common rail version +¥700)
Engine Power：Quanchai: 42kW / East China: 55kW
Transmission：OEM by renowned manufacturer (self-developed technology)
Full-time 4WD：High-low speed / Forward-reverse dual pushrod
Speed：CVT (Continuously Variable Transmission): 27-28 km/h
Performance：Low-speed high torque / Superior off-road capability
Drive System：CVT / Full mechanical gear transmission (Non-traditional cross-axis design)
Axles：Front: Mini planetary reduction axle
Rear: 80° steering angle enables pivot steering (self-developed, ideal for narrow spaces)
Tires：Front: Semi-solid 20.5-16 (Diameter: 880×300mm, off-road tread)
Rear: Semi-solid 7.50-16 (Diameter: 750×190mm, off-road tread)
Brand: Chaoyang
Tire Pressure：6 MPa
Gradeability：Unloaded: 35° / Loaded: 25°
Ground Clearance：Gate frame: 250mm / Chassis: 320mm
Counterweight：Solid cast iron
Tilt AnglesFront tilt/Rear tilt: 12°
Turning Radius：Front wheel: 0.25m / Rear wheel: 2.6m
Wheelbase：2150mm
Notes：Full-time 4WD with central differential (no lock)
Suitable for basements, rental applications, etc.
Adaptable to muddy roads, snowy roads, slopes, and various terrains
Braking System：Front wheel braking
Ex-factory Price：(Excluding tax and transportation)
