Overall Length：3.28m
Overall Width：1.68-1.70m
Overall Height：2.2m
Lifting Height：2 sections 3m (gate frame width 16#)
Gate Frame Origin：Shandong Lai Steel B series
Load Center Distance：500mm
Gate Frame Width (Fully Extended)：Double gate frame width: 800mm, Triple gate frame width: 800mm
Gate Frame Material：20MnSi
Vehicle Curb WeightStandard: 4.8-4.9T, 3-section gate frame: 5.2-5.3T
Engine Brand (National II)：East 55kw, or optional Yunnei 490 turbocharged +2000 yuan
Engine Power：East-55kw, Yunnei-58kw
Transmission：Gearbox (famous brand OEM, self-developed)
Full-time 4WD：High and low speed, forward and reverse double push rod
Speed：Continuous variable speed 27-28km/h
Low speed high torque, off-road performance is more outstanding
Transmission Mode: Continuous Variable Speed：Full mechanical gear transmission (non-traditional spider)
Front Axle: Small Wheel Side Reduction Bridge
Rear Axle: Steering Angle 80°, The vehicle can turn in place, more suitable for narrow spacesSelf-developed
Front TireSemi-solid: 20.5-16, diameter: 880*300mm (semi-solid off-road pattern)
Rear TireSemi-solid: 7.50-16, diameter: 750*190mm (semi-solid off-road pattern), Chaoyang brand
Tire Pressure：6MPa
Gradeability：No load: 35°, load: 25°
Gate Frame Ground Clearance250mm
Ground Clearance：Underbody: 320mm
Counterweight：Solid cast iron counterweight
Forward/Backward Tilt Angle：12°
Minimum Turning Radius：Front wheel: 0.25m, rear wheel: 2.6m
Wheelbase：2150mm
Full-time 4WD Central Differential (Non-locking)Suitable for basements, rentals, and various conditions such as mud, snow, and slopes
Braking Mode：Front wheel brake
Ex-factory Price：Excluding tax and transportation
